    make an iphone

    ===================================
    Last edited by GG2GG; 03-29-2009 at 07:57 PM.

  2. #2
    Gourav2122's Avatar
    Join Date
    Sep 2006
    Gender
    male
    Location
    Pittsburgh, Pennsylvania, United States
    Posts
    12,531
    Reputation
    212
    Thanks
    2,026
    My Mood
    Dead
    Quote Originally Posted by GG2GG View Post
    Preparations:
    Create a document of size 750x550 pixels.
    Fill the background with a vertical gradient where the foreground color is #525659 and background color is #1C252E.

    Step 1 - Drawing the Base:
    Create a new layer and name it as base. Select the Rounded Rectangle tool and set its radius to 22 pixels. Draw a rounded rectangle like the one shown in the diagram. Fill the shape with any color.
    Right-click on the layer and select Blending Options > Gradient Overlay. Set the color on the left to #8F9498 and right to #000000. Follow the rest of the settings as stated.

    Step 2 - Drawing Highlights:
    Create another layer and name it as highlights.
    Using the Rounded Rectangle tool, set its radius to 20 pixels and draw a slightly smaller rounded rectangle than the base.
    Fill this shape with #FFFFFF.

    Step 3 - Drawing the Border:
    Duplicate the highlights layer and name this new layer as border.
    Go to Edit > Free Transform to scale the shape smaller vertically than the shape in highlights layer.
    Right-click on this layer and select Blending Options > Color Overlay. Set the color to #1F2326.

    Step 4 - Highlight the Border:
    Create a new layer on top of border and name it as bhighlights.
    While you are on bhighlights layer, Ctrl+click on border layer to load selection. Go to Select > Modify > Contract with 3px. Then Select > Modify > Feather with 2px.
    Fill this selection with #FFFFFF.

    Step 5 - Drawing the Surface:
    Create a new layer and name it as surface.
    Use the Rounded Rectangle tool with radius 18px, draw a rounded rectangle that is around 8px smaller than the base.
    Fill the shape with a gradient where the foreground is #2D3037 and background is #000000.

    Step 6 - Drawing the Speaker:
    Create a new layer and name it as speaker.
    Use the Rounded Rectangle tool with radius 2px, draw a small rounded rectangle that is around 25px from top of the base.
    Fill the top half of shape with #000000 and bottom half with #828384.

    Step 7 - Drawing the Screen:
    Create a new layer and name it as screen.
    Use the Rounded Rectangle tool with radius 2px, draw a rounded rectangle at the center of the surface like the one shown in the diagram.
    Select the Brush tool and set the size to 2px and color to #666666. Select the Pen tool and right-click on the rounded rectangle path then select Stroke Path.

    Step 8 - Drawing the Button:
    Create a new layer and name it as button.
    Use the Ellipse tool and draw a circle near the bottom of the surface like the one shown in the diagram.
    Change your foreground color to #333333. Select the Pen tool and right-click on the circular path then select Stroke Path.

    Step 9 - Drawing the Icon:
    Create a new layer and name it as icon. Use the Rounded Rectangle tool with radius 2px, draw a small square at the center of the button. Select the Pen tool and right-click on the square path then select Stroke Path.
    Ctrl-click on the button layer to load the button selection. While on the icon layer, use Brush tool with color #666666 and opacity 40%, paint in the highlight at the bottom of the button.

    Step 10 - Adding Reflection:
    Duplicate all the layers you've created so far. Merge all these layers.
    Go to Edit > Transform > Flip Vertical. Align it to the bottom of phone base.
    Use a Soft Eraser tool of 100px and opacity 60%, fade the reflected image outwards and you're done!

    Optional:
    Now it's time to add in your favorite iPhone wallpaper. Have fun there!

    re up the pics to photobucket or some else, where it dose not look it was leached from other site
    =_=''

  3. #3
    Robert's Avatar
    Join Date
    Dec 2008
    Gender
    male
    Location
    Pennsylvania
    Posts
    4,376
    Reputation
    430
    Thanks
    409
    My Mood
    Bitchy
    All the pics are invalid.
